| 產品型號 |
工作電壓(V) |
功耗(mA) |
工作溫度(℃) |
靈敏度(mV/A) |
隔離電壓(V) |
原邊阻抗(mΩ) |
量程(A) |
封裝 |
PDF下載 |
| CC6920 |
4.5~5.5 |
20 |
-40~125 |
400~40 |
3.5kVAC |
0.9 |
±5,±10,±20,±25,±30,±40,±50 |
SOP8 |
暫無 |
| CC6920B |
3~3.6 |
20 |
-40~125 |
264~26.4 |
3.5kVAC |
0.9 |
±5,±10.±20±25
±30,±40,±50 |
SOP8 |
暫無 |
| CC6921 |
4.5~5.5 |
20 |
-40~125 |
200~30.75 |
3.75kVAC |
0.45 |
±10,±20,±30, ±40,±50,±65 |
SOP16W |
暫無 |
| CC6921B |
3~3.6 |
20 |
-40~125 |
132~203 |
3.75kVAC |
0.45 |
±10,±20,±30, ±40,±50,±65 |
SOP16W |
暫無 |
| CC6922 |
3~3.6/4.5~5.5 |
20 |
-40~125 |
100~20/66~13.2 |
5kVAC |
0.3 |
±20,±30,±40,±50,±65,±75,±100 |
SOP16W |
暫無 |
| CC6923 |
3~3.6/4.5~5.5 |
20 |
-40~125 |
100~20/66~13.2 |
5kVAC |
0.3 |
±20,±30,±40,±50,±65,±75,±100 |
SOP16W |
暫無 |
| CC6924 |
3~3.6/4.5~5.5 |
20 |
-40~125 |
100~20/66~13.2 |
5kVAC |
0.3 |
±20,±30,±40,±50,±65,±75,±100 |
SOP16W |
暫無 |
| CC6925 |
3~3.6/4.5~5.5 |
20 |
-40~125 |
1.6~16~29/2.4~24~44 |
/ |
/ |
±200~±1000 |
DFN84x4 |
暫無 |
| CC6926 |
3~3.6/4.5~5.5 |
20 |
-40~125 |
10~6.67/13.2~4.4 |
5kVAC |
0.03 |
±100,±150,+200,+250,+300 |
TO263-7 |
暫無 |
| CC6927 |
4.5~5.5 |
20 |
-40~125 |
40~10/26.4~6.6 |
100VAC |
0.3 |
±50,±100,±150,±200 |
DFN6.4x6.4 |
暫無 |
| CC6928 |
3~3.6/4.5~5.5 |
20 |
-40~125 |
100~20/66~13.2 |
5kVAC |
0.3 |
±20,±30,±40,
±50,±65,±75,±100 |
SOP16W |
暫無 |
| CC6900 |
4.5~5.5 |
5 |
-40~125 |
400~67 |
100VAC |
0.45 |
±5A,±10A,±20A, ±30A |
SOP8 |
暫無 |
| CC6902 |
4.5~5.5 |
5 |
-40~125 |
400~67 |
2kVAC |
0.45 |
±5A,±5B,±10A,±20A,±30A |
SOP8 |
暫無 |
| CC6903 |
3~3.6 |
5 |
-40~125 |
132~44 |
100VAC |
0.45 |
±10A,±20A,±30A |
SOP8 |
暫無 |
| CC6904 |
3~3.6 |
5 |
-40~125 |
132~44 |
2kVAC |
0.45 |
±10A,±20A,±30A |
SOP8 |
暫無 |
| CC6906 |
3~3.6/4.5~5.5 |
20 |
-40~125 |
10~6.67/13.2~4.4 |
100VAC |
0.03 |
±100A,±150A,±200A, ±250A,±300A |
TO263-7 |
暫無 |
| CC6960 |
4.5~5.5 |
20 |
-40~125 |
800~40 |
5.0kVAC |
0.35 |
±6A,±8A,±10A,
±15A,±20A,±30A |
SOP16WG |
暫無 |
| CC6905 |
3~3.6/4.5~5.5 |
20 |
-40~125 |
400~40/264~26.4 |
100VAC |
0.45 |
±5A,±10A,±20A,±30A,
±40A,±50A,+5A,+10A,
+20A,+30A,+40A,+50A |
SOP8
DFN8-3X3 |
暫無 |
成都芯進電子有限公司是一家模擬和混合信號IC設計企業,其中霍爾傳感器技術國內領先.圍繞霍爾傳感器技術開發了速度位置傳感器,高精度線性霍爾傳感器,高精度電流傳感器等產品線.高精度單芯片電流傳感器已經廣泛應用于光伏逆變器,OBC.家電和工業自動化等領域,出貨量居同行業領先水平.
